48V Tracks

by DuraGreen

48V Track offers a modular and decorative lighting solution that brings unlimited flexibility and impeccabledesign to any space. Ideal for premium residential or commercial interiors, this sleek track system effortlessly adds sophistication to your home.



48V Tracks - SURFACE MICRO TRACK

PRODUCT DESCRIPTION Copy link


Code :TC22ST-S
Type :Low voltage track
Material :Aluminum
Finishing :Black
Mounting :Surface/Pendant
IP rating :IP20
Insulation :class III
Control gear :Remote power supply (not included)
Dimensions :W:60mm H:24.6 L: 2000 mm
Cut out for plasterboard :W:34mm * H:>25mm * L
Voltage connection :48 VDC
Circuits :1 x 15 A · 48 VDC
Note :Pendant accessories included

DOWNLOADS


DIMENSIONS


48V Tracks - SURFACE TRACK

PRODUCT DESCRIPTION Copy link


Code :TC22ST
Type :Low voltage track
Material :Aluminum
Finishing :Black
Mounting :Surface
IP rating :IP20
Insulation :class III
Control gear :Remote power supply (not included)
Dimensions :W:26mm H:52 L: 1000 mm | 2000 mm | 3000 mm
Voltage connection :48 VDC
Circuits :1 x 15 A · 48 VDC
Note :The supply connectors, plugs and further fixture accessories must be ordered separately

DOWNLOADS


DIMENSIONS


48V Tracks - SURFACE ROUND TRACK

PRODUCT DESCRIPTION Copy link


Code :TC22ST-C
Type :Low voltage track
Material :Aluminum
Finishing :Black
Mounting :Pendant
IP rating :IP20
Insulation :class III
Control gear :Remote power supply (not included)
Dimensions :W:32mm H:24.5 L: 2000 mm
Voltage connection :48 VDC
Circuits :1 x 15 A · 48 VDC
Note :Pendant accessories included

DOWNLOADS


DIMENSIONS


48V Tracks - TRIMLESS 12.8 TRACK

PRODUCT DESCRIPTION Copy link


Code :TC22ST
Type :Low voltage track
Material :Aluminum
Finishing :Black
Mounting :Surface
IP rating :IP20
Insulation :class III
Control gear :Remote power supply (not included)
Dimensions :W:26mm H:52 L: 1000 mm | 2000 mm | 3000 mm
Voltage connection :48 VDC
Circuits :1 x 15 A · 48 VDC
Note :The supply connectors, plugs and further fixture accessories must be ordered separately

DOWNLOADS


DIMENSIONS


48V Tracks - ARTFOCUS 36 Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20 and IP44 options
Optics :15°/28°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 150mA 6W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - BELLA 41 Zoomable Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Zoomable 20°-50°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K/2700-6000K
Typical Source Efficacy (Im/W) :96
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :12V 600mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - GLAMO 68 Zoomable Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Zoomable 15°-50°
UGR :<17
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 150mA 6W DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - DIVINO 35 Spotlight

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :15°/30°/40°/55°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DIMENSIONS


48V Tracks - ORBIT 35 Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :15°/30°/40°/55°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 150mA 6W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DIMENSIONS


48V Tracks - ORBIT 45 Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DIMENSIONS


48V Tracks - ORBIT 55 Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :12°/24°/36°/45°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 350mA 15W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DIMENSIONS


48V Tracks - ORBIT 65 Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :12°/20°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 700mA 30W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DIMENSIONS


48V Tracks - ORBIT 45 Contour Spotlight

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Framing
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - GLAMO 68 Contour Track Light

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Framing
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off , 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - EVOLINE Dot Line Adjustable Version

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :36° / 65°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K/2700K-6000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 18V 350mA 8W DC 21V 450mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - EVOLINE Dot Line Fixed Version

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :36° / 65°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K/2700K-6000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 18V 350mA 8W DC 21V 450mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - EVOLINE Light Stripe Fixed Version

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :120°
UGR :<19
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K/2700K-6000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 300mA 12W DC 36V 450mA 18W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DOWNLOADS


DIMENSIONS


48V Tracks - EVOLINE Light Stripe Wall Wash

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Wall Wash
UGR :<19
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 21V 450mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - EVOLINE 1124 Dot Line Fixed Version

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :30°/55°/65°/65°Extra Wide/Forward throwing
UGR :<19
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Voltage connection :48 VDC 21W
Luminous efficacy :1624 lm - 3000K
Ambient temp :-20 ℃ to 45 ℃
Class :III

DOWNLOADS


DIMENSIONS


48V Tracks - GLAMO 68 Zoomable Surface Downlight

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Zoomable 15°-50°
UGR :<17
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 150mA 6W DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - BOLUX Surface Downlight

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :10°/24°/36°/55°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 150mA 6W DC 36V 200mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DOWNLOADS


DIMENSIONS


48V Tracks - EVOLINE Surface Downlight

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :50°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 27V 300mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - BELLA 41 Zoomable Wire Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Zoomable 20°-50°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K/2700-6000K
Typical Source Efficacy (Im/W) :96
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :12V 600mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - BELLA 41 Zoomable Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Zoomable 20°-50°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K/2700-6000K
Typical Source Efficacy (Im/W) :96
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48VDC
Output :DC 12V 600mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - GLAMO 68 Zoomable Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :Zoomable 15°-50°
UGR :<17
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 150mA 6W DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - HALO 50 Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :15°/25°/30°/50°/60°
UGR :<10
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 3V 650mA 3W
Ambient temp :-20 ℃ to 45 ℃

DOWNLOADS


DIMENSIONS


48V Tracks - EVOLINE Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :50°
UGR :<17
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 27V 300mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - EVOLINE 1124 Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20
Optics :30°/55°/65°/65°Extra Wide/Forward throwing
UGR :<19
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K
Typical Source Efficacy (Im/W) :113
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Voltage connection :48 VDC 21W
Output :1624 lm - 3000K
Ambient temp :-20 ℃ to 45 ℃
Class :III

DOWNLOADS


DIMENSIONS


48V Tracks - ACME 50 Engine Glass Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20 and IP44 options
Optics :15°/24°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 200mA 8W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - ACME 57 Engine Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20 and IP44 options
Optics :15°/24°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/ 5000K/2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - ACME 68 Engine Glass Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°/340°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Class :III

DIMENSIONS


48V Tracks - ACME 68 Engine Pendant

PRODUCT DESCRIPTION Copy link


IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :48 VDC
Output :DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DIMENSIONS


Why This Light

You might also like

Our team connects creativity with engineering.

We support the seen and the often invisible infrastructure of lighting technology, bringing imagination to light in projects across Australia.

text
