ACME SNOOT

by DuraGreen

✖

ACME SNOOT - 78 Short Snoot

Copy link Share


IP Rating :IP20 and IP44 options
Optics :10°/15°/24°/36°/42°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
✖

ACME SNOOT - 78 Trimless Short Snoot

Copy link Share


IP Rating :IP20 and IP44 options
Optics :10°/15°/24°/36°/42°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
✖

ACME SNOOT - 78 Long Snoot

Copy link Share


IP Rating :IP20 and IP44 options
Optics :10°/15°/24°/36°/42°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
✖

ACME SNOOT - 78 Trimless Long Snoot

Copy link Share


IP Rating :IP20 and IP44 options
Optics :10°/15°/24°/36°/42°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
