ACME STRAIGHT

by DuraGreen

The ACME STRAIGHT is our downlight range, featuring a straight baffle for projects that require higher lumen output and dark reflector lighting. Unparalleled in versatility, ACME’s lighting fixtures are designed with the needs of premium residential and commercial spaces in mind.

✖

ACME STRAIGHT - 36 Straight Fixed

Copy link Share

IP Rating :IP20
Optics :24°
UGR :<10
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K
Typical Source Efficacy (Im/W) :103
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 12V 300mA 5W
Ambient temp :-20 ℃ to 45 ℃
Class: :II

DOWNLOADS

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 36 Straight Trimless Fixed

Copy link Share

IP Rating :IP20
Optics :24°
UGR :<10
CRI :92Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :3000K/3500K
Typical Source Efficacy (Im/W) :103
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 12V 300mA 5W
Ambient temp :-20 ℃ to 45 ℃
Class: :II

DOWNLOADS

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 50 Straight Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 100mA 4W DC 36V 150mA 6W DC 36V 200mA 8W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 50 Straight Trimless Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 100mA 4W DC 36V 150mA 6W DC 36V 200mA 8W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 57 Straight Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 150mA 6W DC 36V 200mA 8W DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 57 Straight Trimless Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 150mA 6W DC 36V 200mA 8W DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 68 Straight Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 68 Straight Trimless Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 68 Straight Fixed Shallow

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 68 Straight Trimless Fixed Shallow

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 78 Straight Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 78 Straight Fixed

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 78 Straight Trimless Adjustable

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
✖

ACME STRAIGHT - 78 Straight Trimless Fixed

Copy link Share

IP Rating :IP20 and IP44 options
Optics :15°/24°/36°/50°
UGR :<10
CRI :98Ra
Lifetime :>50,000 hrs (L70 B10)
CCT :2700K/3000K/3500K/4000K/5000K/ 2000K-3000K/1800K-4000K/2700K-6000K
Typical Source Efficacy (Im/W) :110
Control :On/off, Mains Dim, 0/1-10V, Dali, Zigbee, Casambi
Binning :2 Step MacAdams
Input :AC220-240V 50/60Hz
Output :DC 36V 200mA 8W DC 36V 250mA 10W DC 36V 300mA 12W
Ambient temp :-20 ℃ to 45 ℃
Optionsl Accessories :Honeycomb louvre, Solite Lense, Spread Lense, Colour Filter

DOWNLOADS

Certifications

DIMENSIONS

Contact Us
